trapezoidal-shee-roll-forming-machine

Technical Specifications

Profile Type: RD 91.5

Effective Width: 915 mm

Coil Width: 1220 mm (customizable)

Material Thickness: 0.2 – 0.8 mm

Forming Speed: 10 – 15 m/min

Roll Stations: 24 – 28 steps

Roller Material: 45# Steel, quenched, hard-chrome plated

Machine Frame: Welded mid-plate structure

Transmission: Chain Drive

Cutting: Hydraulic Guide Pillar Cutting System

Control System: PLC Automatic Control with Touchscreen

Main Motor Power: 11 KW (adjustable)

Hydraulic Station Power: 5.5 KW

Key Features

Specially Designed for Structural Panels:
Molds dedicated to high-profile deep corrugated panels, providing strong forming strength.More Stable Heavy-Duty Frame:
The entire machine uses a 14–18mm thick welded steel base, ensuring heavy-load stability.Guide Post Shearing System:
High-strength steel guides provide smooth, impact-resistant shearing.Chain Drive with Easy Maintenance:
Reliable and durable, suitable for long-term continuous operation.

Customization Supported:
Molds and the number of rollers can be customized according to customer’s panel drawings.Intelligent Operation:
PLC with touchscreen control for precise counting and adjustable length.

Application Scope

Composite Decking

Structural Roof Deck

Industrial buildings

Formwork Systems

Steel Buildings and Infrastructure

Optional Equipment

Manual Uncoiler

Electric Uncoiler

Fully Automatic Hydraulic Uncoiler (without Coil Car)

Fully Automatic Hydraulic Uncoiler with Coil Car

Simple Discharge Rack / Manual Stacker

Electric Discharge Rack / Electric Stacker

Fully Automatic Stacking Machine / Automatic Stacker
